How to Visualize Your Data with Dimension Reduction Techniques

Comparing and Contrasting PCA, t-SNE, and UMAP

These days, everyone is excited about embeddings — numeric vectors that represent features of your input data. In computer vision for instance, image embeddings are used in reverse image search applications. And in the context of large language models (LLMs), documents are chunked and embedded (with text embedding models) for retrieval augmented generation (RAG).

Embeddings are incredibly powerful, but given their high dimensionality (with lengths typically between 384 and 4096), they can be hard for humans to interpret and inspect. This is where dimensionality reduction techniques come in handy!

Dimensionality reduction techniques are quantitative methods for representing information from a higher dimensional space in a lower dimensional space. By squeezing our embeddings into two or three dimensions, we can visualize them to get a more intuitive understanding of the “hidden” structure in our data.

When we project high dimensional data into a low dimensional space, we implicitly make a trade-off between representational complexity and interpretability. To compress embeddings, dimensionality reduction techniques make assumptions about the underlying data, its distribution, and the relationships between variables.

In this post, we will visualize embeddings using four popular dimensionality reduction techniques: PCA, t-SNE, and UMAP. We will give a brief overview of the strengths, weaknesses, and assumptions of each technique. And we will illustrate that both the model used to generate embeddings, and the dimensionality reduction technique play essential roles in shaping the visualization of your data.

Before getting into the details, it is important to note that dimensionality reduction techniques often have hyperparameters, which can have non-negligible impacts on the results. In this post, I am going to use the default hyperparameters everywhere that choices arise. Feel free to modify as you see fit!

Setup

For this walkthrough, we will be using the FiftyOne library for data management and visualization. We will use scikit-learn for PCA and t-SNE, and umap-learn for UMAP dimension reduction implementations:

pip install -U fiftyone scikit-learn umap-learn

We will be using the test split of the CIFAR-10 dataset as our testbed, which contains 10,000 images of size 32×32 pixels, spanning 10 image classes. We can load the dataset/split directly from the FiftyOne Dataset Zoo:

import fiftyone as fo
import fiftyone.brain as fob
import fiftyone.zoo as foz

dataset = foz.load_zoo_dataset("cifar10", split="test")
session = fo.launch_app(dataset)

We will also compare and contrast our four dimensionality reduction techniques with two image embedding models: ResNet-101 and CLIP. Whereas ResNet-101 is a more traditional vision model, representing the relationships between pixels and patches in images, CLIP captures more of the semantic content of the images.

We can load both of these models from the FiftyOne Model Zoo:

clip = foz.load_zoo_model("clip-vit-base32-torch")
resnet101 = foz.load_zoo_model("resnet101-imagenet-torch")

Then generating embeddings for each model amounts to making a single call to the dataset’s compute_embeddings() method:

## compute and store resnet101 embeddings
dataset.compute_embeddings(
    resnet101,
    embeddings_field="resnet101_embeddings"
)

## compute and store clip embeddings
dataset.compute_embeddings(
    clip,
    embeddings_field="clip_embeddings"
)

Dimensionality Reduction with PCA

Principal Component Analysis, or PCA, is a dimensionality reduction technique that seeks to preserve as much variance as possible. Intuitively, PCA finds a set of orthogonal axes (principal components) that jointly “explain” as much of the variation in the data as possible. Mathematically, you can interpret PCA algorithms as effectively performing singular value decompositions and truncating the number of dimensions by eliminating the singular vectors with the smallest eigenvalues.

Strengths

  • Simple, intuitive, and efficient for large datasets!
  • PCA is amenable to new data: If you have precomputed the transformation on an initial set of embeddings, you can apply that transformation to new embeddings and immediately visualize them in the same space.

Limitations

  • Assumes that the relationships between variables are linear — an assumption which often does not hold when the inputs are embeddings, which themselves come from highly nonlinear deep neural networks.
  • Very susceptible to outliers.

Running PCA on Embeddings

PCA is natively supported by the FiftyOne Brain’s compute_visualization(). To reduce dimensionality for a set of embeddings, we can specify the field the embeddings are stored in, and pass in method=”pca". We will store the results with brain keys so we can access them in the FiftyOne App:

## PCA with ResNet101 embeddings
fob.compute_visualization(
    dataset,
    embeddings="resnet101_embeddings",
    method="pca",
    brain_key="resnet101_pca"
)

## PCA with CLIP embeddings
fob.compute_visualization(
    dataset,
    embeddings="clip_embeddings",
    method="pca",
    brain_key="resnet101_pca"
)

In the app, we can open up an Embeddings panel to view the results:

Dimensionality reduced ResNet-101 embeddings using PCA

We can color by any attribute on our samples — in this case the ground truth label — and filter the contents of the sample grid interactively by selecting regions in the embeddings panel.

Dimensionality reduced CLIP embeddings using PCA

For both the CLIP and ResNet-101 embeddings, the PCA plot does seem to very loosely retain information from the embeddings (and the original images). However, when we color by label, there is substantial overlap from one class to another.

Restricting the CLIP PCA view to just automobiles, trucks, and ships, we can see that the distributions for all three classes are essentially identical, aside from the ships extending slightly farther out.

Overlap in distributions of automobiles, ships, and trucks in the CIFAR-10 dataset, after applying PCA to CLIP embeddings.

Dimensionality Reduction with t-SNE

t-Distributed Stochastic Neighbor Embedding, or t-SNE, is a nonlinear dimensionality reduction technique that aims to, roughly speaking, keep neighbors close. More precisely, t-SNE takes the initial, high-dimensional data (in our case embedding vectors) and computes the similarity between inputs. The algorithm then attempts to learn a lower-dimensional representation which preserves as much of the similarity as possible. Mathematically, this learning is achieved by minimizing the Kullback-Leibler divergence between the high-dimensional (fixed) and low-dimensional (trained) distributions.

Strengths

  • t-SNE is nonlinear, making it a much better fit for (embeddings computed on) datasets like MNIST and CIFAR-10.
  • The technique is good at preserving local structure, making it easy to see clustering in data!

Limitations

  • t-SNE relies on random initialization, so good fits are not guaranteed
  • Still sensitive to outliers
  • Not scalable: for a dataset with n samples, t-SNE takes O(n²) time to run, and requires O(n²) space to operate

Running t-SNE on Embeddings

Like PCA, t-SNE is natively supported by the FiftyOne Brain’s compute_visualization(), so we can run dimensionality reduction on our embeddings by passing method="tsne”:

## t-SNE with ResNet101 embeddings
fob.compute_visualization(
    dataset,
    embeddings="resnet101_embeddings",
    method="tsne",
    brain_key="resnet101_tsne"
)

## t-SNE with CLIP embeddings
fob.compute_visualization(
    dataset,
    embeddings="clip_embeddings",
    method="tsne",
    brain_key="resnet101_tsne"
)

Looking at the results of t-SNE dimensionality reduction on both ResNet-101 and CLIP embeddings, we can see a lot more separation between the distributions of different classes.

Dimensionality reduced ResNet-101 embeddings using t-SNE

In both cases, similar classes are still close to each other — for instance, automobiles and trucks are adjacent — but we can also mostly distinguish a main cluster for almost every class. In other words, t-SNE does a very good job at capturing local structure, and a decent job at capturing global structure.

Dimensionality reduced CLIP embeddings using t-SNE

Dimensionality Reduction with UMAP

Uniform Manifold Approximation and Projection (UMAP) is a nonlinear dimensionality reduction technique based on the mathematics of topology. I won’t go into the gory details, as there is an excellent visual explanation of the approach here, but in essence, UMAP treats the input data as points lying on a special kind of surface called a manifold (technically here a Riemannian manifold), and tries to learn a lower dimensional representation of the manifold. This explicitly takes global structure into consideration, as opposed to t-SNE, which concerns itself with keeping neighbors close (local structure).

Strengths

  • Preserves both global and local structure
  • Better scaling than t-SNE with dataset size

Limitations

  • Like t-SNE, UMAP relies on randomness, and is dependent upon hyperparameters
  • UMAP assumes that the manifold is locally connected. This can cause problems if there are a few data points that are very far away from the rest of the data.

Running UMAP on Embeddings

Like PCA and t-SNE, UMAP is natively supported by the FiftyOne Brain’s compute_visualization(), so we can run dimensionality reduction on our embeddings by passing method=”umap":

## UMAP with ResNet101 embeddings
fob.compute_visualization(
    dataset,
    embeddings="resnet101_embeddings",
    method="umap",
    brain_key="resnet101_umap"
)

## UMAP with CLIP embeddings
fob.compute_visualization(
    dataset,
    embeddings="clip_embeddings",
    method="umap",
    brain_key="resnet101_umap"
)

For both sets of embeddings, the clusters are a lot more spread out than with t-SNE. For ResNet-101, all of the vehicles (automobile, truck, airplane, ship) are in one mega-cluster — or two smaller clusters, depending on how you view it — and all of the animals are in another mega-cluster.

Dimensionality reduced ResNet-101 embeddings using UMAP

Interestingly, for the CLIP embeddings, we see that the airplane cluster is situated close to both bird and ship. The car and truck clusters are very close together; and the cat and dog clusters are very close together.

Dimensionality reduced CLIP embeddings using UMAP

Dimensionality Reduction with Custom Methods

Depending on the specific structure of your data, you may find that none of the techniques detailed above provide an intuitive view into your data. Fortunately, there are tons of other techniques you can use. In this section, we’ll show you how to run custom dimensionality reduction techniques with FiftyOne.

Isomap

Like UMAP, Isomap is also a nonlinear manifold learning technique. Isomap is built into scikit-learn, so we can fit our high-dimensional data and generate low-dimensional transformed data points as follows:

import numpy as np
from sklearn.manifold import Isomap

## get embeddings from dataset
embeddings = np.array(dataset.values("resnet101_embeddings"))

## create and fit
manifold_embedding = Isomap(n_components=2)
z = manifold_embedding.fit_transform(embeddings)

We can then create a visualization in FiftyOne by passing method=”manual" into compute_visualization() and providing these lower-dimensional points via the points argument:

fob.compute_visualization(
    dataset,
    method='manual',
    points=z,
    brain_key='resnet101_isomap'
)
Dimensionality reduction of ResNet-101 embeddings with Isomap.

Any dimensionality reduction method supported by scikit-learn can be used in analogous fashion.

CompressionVAE

CompressionVAE uses Variational Autoencoders to deterministically and reversibly transform the high-dimensional data into a lower dimensional space.

To run CompressionVAE, clone this forked repo:

git clone https://github.com/jacobmarks/CompressionVAE.git

Then cd into the directory and install the package locally:

cd CompressionVAE
pip install .

Embed the input data (embeddings) into a lower-dimensional space, and create a visualization in FiftyOne via the same manual method:

from cvae import cvae

X = np.array(dataset.values("clip_embeddings"))

embedder = cvae.CompressionVAE(X)
embedder.train()
z = embedder.embed(X)

fob.compute_visualization(
    dataset,
    method='manual',
    points=z,
    brain_key='clip_cvae'
)
Dimensionality reduction of CLIP embeddings with CompressionVAE.

Conclusion

Dimensionality reduction is critical to understanding our data, and our models. But it is important to think of dimensionality reduction not just as a single tool, but rather as a collection of techniques. Each technique has its own advantages; and each method projects certain assumptions onto the data, which may or may not hold for your data. I hope this walkthrough helps you to see your data in a new way!
